By combining product conveying, detection, label dispensing, and label application in one streamlined operation, the machine helps manufacturers improve production efficiency and achieve a more consistent packaging appearance. The machine supports stepless speed adjustment, allowing it to match different production capacities and line speeds. It can operate independently or work together with other machines as part of a complete production system.
When no product or material is detected, the control system automatically stops label dispensing, reducing unnecessary label consumption and preventing incorrect labeling. Its stable conveying and labeling structure ensures neat label placement and helps maintain a professional product presentation. The inline labeling machine offers strong adaptability for round bottles in various sizes, colors, and materials, and can be adjusted according to specific product and labeling requirements.
The inline labeling machine is widely used in pharmaceutical, food, beverage, daily chemical, light industry, and related packaging fields.
Typical applications include medicine bottles, beverage bottles, cosmetic containers, seasoning bottles, health product bottles, and other cylindrical packaging products.
For manufacturers looking to upgrade automation, reduce manual labor, and maintain stable labeling quality across large-volume production, the inline labeling machine provides a practical and efficient online labeling solution.
|
Voltage
|
AC220V 50/60Hz (default and variable if needed)
|
|
Power
|
980W
|
|
Capacity
|
0~20m/min(step) ; 0~40m/min(servo)
|
|
labeling speed
|
3000 bottles per hour (depending on the size of bottle, label length, production line, etc.)
|
|
Accuracy
|
±1mm(depends on object&label sizes and labeling pattern)
|
|
machine net weight
|
200KG
|
|
Dimension
|
(L*W*H) 1000*800*1100mm
|
|
Conveyor Width
|
Can be customized according to the diameter of the sample bottle
|
|
Label Size
|
H100mm~400mm; L15~300mm(Can be customized)
|
|
Size of Paper Roll
|
Inner diameter of label roll: Ф76mm;
Outer diameter of label roll: Ф300mm
|
|
Single label spacing
|
≥3mm
|
|
Labeling thickness
|
≥8um, backing paper thickness ≥5um, and allowing for there is a certain degree of tensile strength.
|
|
Bottle outer diameter range
|
Ф18-120mm
|
|
Product size
|
(Optional conveyor)
|
|
Length (conveying direction)
|
100-600mm
|
|
Width (conveying width)
|
100-500mm
|
|
Height
|
100mm~600mm (Customizable according to customer requirements)
|
